Addressable Wireless Fire Alarm Panel

Model: PTSWAFAPeX
Wireless Addressable Fire Alarm Panel

Features
  • Touch Screen Display
  • Fully Addressable
  • Field Programmable
  • Simple to Install
  • Soft Addressing
  • Minimize cable cost
  • User friendly interface
Approvals
CE Approved Certified

Addressable Wireless Fire Alarm Control Panel is the core component of the Fire Detection system. Our panel uses state of the art RF wireless communication technology for communication bundled with self test and supervisory features. PTS-eX Series of Wireless Addressable Fire Alarm Control panels is engineered for residential, commercial and industrial applications with features that minimize installation cost and time. Touch Screen TFT further simplifies the system operation, installation and maintenance. They offer the design flexibility, expansion compatibility and operation reliability for large scale installations.

In addition the panel includes networking capabilities to monitor the status from any remote location or in your mobile phone, an internal buzzer and battery backup.

Download Datasheet
Product Specification
Product Class Addressable
Opetaring Voltage 230V AC ±10%-15% (nom)
Secondary Supply 2 x 1.3ah Battery
Operating Temperature -10°C to +55°C
Humidity <95% Non Condensed
Color Red
Addressing Method Electronic
Addressing Capacity 250 devices
Housing Mild Steel
